1
Engine displacement
350
2
Model
X10
3
Year
2014
4
Trim
X10 4T 4V I.E. E3
5
Parts Catalog
Front wheel
6
Parts Diagram
Parts Catalog
Central cover - Footrests
by
Rocking levers support unit
Front wheel
1
2
3
4
5
6
7
8
8
9
9
10
10
11
11
12
12
13
13
14
15
16
1
Front wheel complete
667856
£205,24 Unit Price incl. VAT
2
Bearing 20x47x14
434735
£17,32 Unit Price incl. VAT
3
Circlip
006647
Not Available
4
Bearing internal spacer
667863
£39,31 Unit Price incl. VAT
5
Radial ball bearing
649565
Not Available
6
Tubeless valve
597679
£6,16 Unit Price incl. VAT
7
(Michelin) Front tyre 120/70-15"
668140
£169,48 Unit Price incl. VAT
7
Front tyre (Sava) 120/70-15"
668142
Not Available
8
Cup
667869
£7,28 Unit Price incl. VAT
9
Front wheel spacer
667868
£14,57 Unit Price incl. VAT
10
Brake disc
668824
£72,52 Unit Price incl. VAT
11
Hex socket screw
564606
£1,12 Unit Price incl. VAT
12
Bush
667828
£5,47 Unit Price incl. VAT
13
Ring
AP8121641
£4,32 Unit Price incl. VAT
14
Front wheel spindle
667870
Not Available
15
DAX flange nut M16x1,25
AP8221329
Not Available
16
ABS phonic wheel
667829
Not Available

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
