1
Engine displacement
300
2
Model
X7
3
Year
2009
4
Trim
X7 ie Euro 3
5
Parts Catalog
Voltage Regulators - Electronic Control Units (ecu) - H.T. Coil
6
Parts Diagram
Parts Catalog
Remote control switches - Battery - Horn
by
Main cable harness
Voltage Regulators - Electronic Control Units (ecu) - H.T. Coil
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
Voltage regulator
58209R
Not Available
2
Screw w/ flange M6x30
289731
Not Available
3
HT coil
58120R
£53,05 Unit Price incl. VAT
4
Spark.plug protection clamp
641643
£9,05 Unit Price incl. VAT
4
Spark.plug protection clamp
641219
Not Available
5
Insulating cap
641040
£7,73 Unit Price incl. VAT
5
Screened cap
969348
£15,46 Unit Price incl. VAT
6
H.V. cable
080341
Not Available
7
Flexible support
291017
£13,44 Unit Price incl. VAT
8
Turn indicator control
638755
Not Available
9
Support clamp
640746
Not Available
10
Lock-strap L=180mm
145298
£1,14 Unit Price incl. VAT
10
Hose clamp
641764
£0,73 Unit Price incl. VAT
11
H.v. coil bracket
641758
£10,12 Unit Price incl. VAT
12
screw M3x20
583236
£1,27 Unit Price incl. VAT
13
Washer 3.2x5.7x0.9
012554
Not Available
14
Washer
013836
Not Available
15
Nut M 3
020003
Not Available

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
