1
Engine displacement
400
2
Model
X8
3
Year
2007
4
Trim
X8 ie (Euro 3)
5
Parts Catalog
Locks
6
Parts Diagram
Parts Catalog
Handlebars - Master cil.
by
Locks
1
2
3
4
5
6
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1
Lock body
298581
Not Available
2
Metric screw TBC
259348
£1,04 Unit Price incl. VAT
3
Complete lock block
298903
Not Available
4
Flat washer
298594
£1,24 Unit Price incl. VAT
5
Cylinder retainer spring
298838
£1,69 Unit Price incl. VAT
6
Saddle/flap tightening
CM023704
£24,30 Unit Price incl. VAT
6
Saddle lock
CM023701
£34,99 Unit Price incl. VAT
9
Spring
253937
£2,00 Unit Price incl. VAT
10
Special screw
299972
£1,14 Unit Price incl. VAT
11
Self locking nut
577620
£0,97 Unit Price incl. VAT
12
Cylinder with keys
620281
Not Available
13
Gasket ring
298731
£1,00 Unit Price incl. VAT
14
Hewn key with transponder
621306
Not Available
15
Pawl
621162
£2,02 Unit Price incl. VAT
16
Immobilizer antenna
828800
Not Available
17
Screw M6x16
272836
£1,13 Unit Price incl. VAT
18
Self locking nut
577620
£0,97 Unit Price incl. VAT
19
Hexagonal-head screw
584121
£10,69 Unit Price incl. VAT
20
Special screw
299972
£1,14 Unit Price incl. VAT
21
Joint
577128
£3,71 Unit Price incl. VAT
22
Lever
577129
£6,18 Unit Price incl. VAT
23
Spring
577131
£3,31 Unit Price incl. VAT
24
Self locking nut
577620
£0,97 Unit Price incl. VAT
25
Solenoid valve
582990
Not Available
26
Spring
620415
£4,94 Unit Price incl. VAT
27
plate
621605
£14,12 Unit Price incl. VAT
28
Lock-strap L=180mm
145298
£1,14 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
