1
Engine displacement
200
2
Model
RUNNER
3
Year
2006
4
Trim
Runner VXR 4T E3
5
Parts Catalog
Head unit - Valve
6
Parts Diagram
Parts Catalog
Cylinder-piston-wrist pin unit
by
Rocking levers support unit
Head unit - Valve
1
2
2
3
3
4
4
5
5
6
7
8
9
9
10
11
12
14
16
17
19
23
24
26
27
1
Cylinder head assembly
847594
Not Available
2
Valve half-cone
285846
£1,98 Unit Price incl. VAT
3
Valve gasket ring
436438
£11,03 Unit Price incl. VAT
4
Lower cap
483711
£2,12 Unit Price incl. VAT
5
Upper cap
483914
£5,71 Unit Price incl. VAT
6
Intake valve
484733
Not Available
6
Intake valve
872999
Not Available
7
Exhaust valve
873114
Not Available
7
Exaust valve
484734
Not Available
8
Thermistor
82622R
£25,90 Unit Price incl. VAT
9
Spring
828480
£11,04 Unit Price incl. VAT
10
Stud bolt M7
435629
£1,87 Unit Price incl. VAT
11
Exhaust pipe gasket
480853
£5,16 Unit Price incl. VAT
12
Hose clamp
CM002903
£0,24 Unit Price incl. VAT
13
Locating dowel Ø7,5x12
277916
£6,38 Unit Price incl. VAT
14
Nut M8x1,25
411296
£1,97 Unit Price incl. VAT
15
Locating dowel Ø11x10
478115
Not Available
16
Screw w/ flange
485603
£1,96 Unit Price incl. VAT
17
Cylinder head gasket 0,3 mm
831174
£19,27 Unit Price incl. VAT
19
Hex socket screw M5x20
845753
Not Available
23
Thermostat
82831R
Not Available
24
Cover
828263
£10,46 Unit Price incl. VAT
26
By-pass pipe
434381
£9,40 Unit Price incl. VAT
27
Head-carb.by-pass pipe
827921
£5,26 Unit Price incl. VAT
28
O-ring
478184
Not Available

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
