1
Engine displacement
150
2
Model
LX
3
Year
2006
4
Trim
LX 4T E3
5
Parts Catalog
Crankcase cover - Crankcase cooling
6
Parts Diagram
Parts Catalog
Rocking levers support unit
by
Central cover - Footrests
Crankcase cover - Crankcase cooling
1
2
3
4
5
6
7
8
12
13
16
17
19
21
22
23
24
1
Transmission cover with U.P.
8721165
Not Available
2
Bush Ø8xØ12x8
431860
£1,43 Unit Price incl. VAT
3
Bearing
478985
Not Available
4
Snap ring
006635
Not Available
5
Pin 6,5x9,5x15
239388
Not Available
6
Screw w/ flange M6x30
289731
Not Available
7
Hose clamp
844964
£1,99 Unit Price incl. VAT
8
Cover
484726
£8,88 Unit Price incl. VAT
9
Retainer buffer
871458
£1,72 Unit Price incl. VAT
12
Cooling tube
576267
£34,61 Unit Price incl. VAT
13
Expansion plug
199190
£0,17 Unit Price incl. VAT
16
Lock-strap L=180mm
145298
£1,14 Unit Price incl. VAT
17
Bellows
298548
£18,34 Unit Price incl. VAT
19
Self tapping screw L=20 mm
267958
£0,76 Unit Price incl. VAT
21
Air deflector
841228
Not Available
22
Plug
CM121908
Not Available
23
Self-tap screw M3x20
258146
£0,65 Unit Price incl. VAT
24
Self-tapping screw
430264
£0,62 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
