1
Engine displacement
250
2
Model
BV
3
Year
2006
4
Trim
BV
5
Parts Catalog
Rear headlamps - Turn signal lamps
6
Parts Diagram
Parts Catalog
Front headlamps - Turn signal lamps
by
Remote control switches - Battery - Horn
Rear headlamps - Turn signal lamps
1
2
3
4
5
6
7
8
9
10
11
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
1
Taillight
583990
Not Available
2
Bulb 12V-15W
584354
£4,82 Unit Price incl. VAT
3
Lamp 12V-3W
294131
£2,70 Unit Price incl. VAT
4
Bulb 12V-5W
181747
Not Available
5
Spring plate
CM017409
£1,27 Unit Price incl. VAT
6
Expansion plug
199190
£0,17 Unit Price incl. VAT
7
Metric screw TBC
575249
£0,62 Unit Price incl. VAT
8
Spring plate M6
254485
£1,64 Unit Price incl. VAT
9
Left sideburn
584125
£11,51 Unit Price incl. VAT
10
Right sideburn
584124
£11,51 Unit Price incl. VAT
11
Self-tapping screw
018623
Not Available
11
Self-tapping screw M5x12
015585
Not Available
12
Plain washer 5,4x10x0,8
003055
Not Available
13
Nut
020105
Not Available
14
Bracket
584101
Not Available
15
Bracket
584114
Not Available
16
Turn sign.
584095
£47,11 Unit Price incl. VAT
17
Lamp 12V-10W
181746
£2,92 Unit Price incl. VAT
18
Glass
584208
Not Available
19
Turn sign.
584096
Not Available
20
Lamp 12V-10W
181746
£2,92 Unit Price incl. VAT
21
Glass
584208
Not Available
22
Rear licence plate light
583332
Not Available
23
Lamp 12V-5W
292022
Not Available
24
Wire
583331
Not Available
25
Self tapping screw M4x16
267115
£0,62 Unit Price incl. VAT
26
Washer 4,3x8x0,5
003054
Not Available

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
