1
Engine displacement
250
2
Model
NEXUS
3
Year
2006
4
Trim
Nexus E3
5
Parts Catalog
Driving pulley
6
Parts Diagram
Parts Catalog
Swinging arm
by
Engine, assembly
Driving pulley
2
14
13
12
11
10
9
8
7
6
5
3
1
1
Complete roller housing
CM144408
Not Available
2
Spacer
483889
£35,44 Unit Price incl. VAT
3
Roller contrast
842204
£14,02 Unit Price incl. VAT
4
Roller contrast
485710
£14,02 Unit Price incl. VAT
5
Pin roller
849480
£2,99 Unit Price incl. VAT
6
Sliding block
843028
£2,59 Unit Price incl. VAT
7
Fixed pulley
840193
£41,65 Unit Price incl. VAT
8
V-belt
843963
Not Available
9
Plain washer 17x32x1
434885
£1,91 Unit Price incl. VAT
10
Nut M12x1.25
486324
£1,04 Unit Price incl. VAT
11
Flat washer 12.1x36x2
840533
£2,30 Unit Price incl. VAT
12
Belleville spring 0,5x35x17
841379
Not Available
13
Toothed pulley
833989
£67,72 Unit Price incl. VAT
14
Bearing
82642R
Not Available
14
Special screw
828217
£1,58 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
