SWING ARM - SHOCK ABSORBER FOR GILERA SMT 50 2015

Tank - Air box - Saddle

Item numbers

SWING ARM WITH MACHINED BUSHES

86482902WGB

Contact

REAR WHEEL AXLE SUB-ASSEMBLY G
REAR WHEEL AXLE SUB-ASSEMBLY G

00H01304202

00H013042025

£16,10

Unit Price Incl. Tax

WASHER

00003112322

Contact

BUSH

00002503230

Contact

SPACER

00H00301401

£13,29

Unit Price Incl. Tax

WASHER

00D01300192

£2,15

Unit Price Incl. Tax

SCREW 6MX100X12

00012061200

Contact

SCREW
SCREW M4, 8X13

00011041300

AP8150246

£4,51

Unit Price Incl. Tax

CHAIN GUIDE PLATE

00H01803331

£18,11

Unit Price Incl. Tax

REAR SHOCK ABSORBER

8670020001

£345,11

Unit Price Incl. Tax

VITE M12X58X175

00H00303892

£7,50

Unit Price Incl. Tax

WASHER

00003115422

Contact

NUT 12MX175

00023112000

Contact

WASHER

847226

£0,49

Unit Price Incl. Tax

FAIRLEAD

864114

£7,50

Unit Price Incl. Tax

CHAIN GUARD

00H01508181

£31,10

Unit Price Incl. Tax

SCREW 6M100X16

00H05900021

£4,91

Unit Price Incl. Tax

WASHER D6

00D01200171

£1,21

Unit Price Incl. Tax

SPRING PLATE M6
SPRING PLATE (M6)

00D01501371

254485

£1,57

Unit Price Incl. Tax

SCREW 4, 8X13

00011141300

Contact

SCREW 12X45

00H00300912

£4,91

Unit Price Incl. Tax

DECAL

8657130001

£11,65

Unit Price Incl. Tax

DECAL

8657120001

£11,65

Unit Price Incl. Tax

NUT

00262120032

Contact

CHAIN GUIDE PLATE

00H01305171

£16,16

Unit Price Incl. Tax

WASHER D6 DIN125 AZNB

00402060001

Contact

NUT M6100

00000023060

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from GILERA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Swing arm - Shock absorber of your GILERA SMT 50 of SMT. Let us know if you have any questions.
