CONTROL PEDALS - LEVERS FOR GILERA FUOCO 4T-4V IE E3 LT 2013

Transmissions

Item numbers

BRAKE PUMP, ASSY

CM082901

£144,10

Unit Price Incl. Tax

PUMP SUPPORT BRACKET COMPLETE WITH BRAKE PEDAL

665581

£354,03

Unit Price Incl. Tax

BELLOWS

672133

£20,92

Unit Price Incl. Tax

SELF LOCKING NUT M10

002440

FLAT WASHER

178790

£1,57

Unit Price Incl. Tax

BUSH

650636

£9,43

Unit Price Incl. Tax

SPRING

650670

£4,41

Unit Price Incl. Tax

HEX SCREW M6X20

018639

Contact

650651

£12,43

Unit Price Incl. Tax

SPLIT PIN

012761

Contact

TUBAZIONE FRENO (POMPA SX - VALV. ANT.)

650722

1C005537

£58,19

Unit Price Incl. Tax

SCREW W/ FLANGE M6X16

B016777

£1,21

Unit Price Incl. Tax

HEX SOCKET SCREW M8X16

031116

Contact

LOW SELF-LOCKING NUT

709052

Contact

PEDAL FORK WITH U.P.

650711

£30,83

Unit Price Incl. Tax

BRAKE PEDAL RUBBER

228793

£8,60

Unit Price Incl. Tax

SCREW

582469

£1,21

Unit Price Incl. Tax

SELF LOCKING NUT M6

195482

£1,21

Unit Price Incl. Tax

BRAKE OIL TANK

274598

£63,59

Unit Price Incl. Tax

COVER

498431

£23,90

Unit Price Incl. Tax

BREAK PIPES

1C000117

£81,97

Unit Price Incl. Tax

SELF TAPPING SCREW D4.2X13

CM178603

£1,79

Unit Price Incl. Tax

SPRING PLATE

CM017409

£1,21

Unit Price Incl. Tax

ANTI-TILTING DEVICE OIL PUMP TANK RETURN PIPE

650772

£27,52

Unit Price Incl. Tax

HOSE CLAMP

CM002905

£0,17

Unit Price Incl. Tax

HOSE CLAMP

CM002907

£1,21

Unit Price Incl. Tax

LOCK-STRAP L=180MM

145298

£1,09

Unit Price Incl. Tax

LOCK-STRAP L=277

257134

£0,45

Unit Price Incl. Tax

FRONT PRESSURE ADJUSTMENT VALVE.

CM082803

£166,64

Unit Price Incl. Tax

VIS À TÊTE HEXAGONALE BRIDÉE M6X40
FLANGED HEXAGONAL SCREW M6X40

B016763

1A011120

£0,41

Unit Price Incl. Tax

BRACKET WITH UP

2B000823

£15,05

Unit Price Incl. Tax

REAR PRESSURE ADJUSTMENT VALVE

CM082802

£233,09

Unit Price Incl. Tax

BRACKET WITH U.P.

650625

£15,21

Unit Price Incl. Tax

SCREW W/ FLANGE M6X16

B016777

£1,21

Unit Price Incl. Tax

OIL PIPE SCREW M10X18

265451

£2,40

Unit Price Incl. Tax

GASKET

127927

£0,99

Unit Price Incl. Tax

BREAK PIPES

650720

£49,03

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from GILERA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Control pedals - Levers of your GILERA Fuoco 4T-4V ie E3 LT of FUOCO. Let us know if you have any questions.
