FRONT GLOVE-BOX - KNEE-GUARD PANEL FOR PIAGGIO CARNABY 4T E3 2010

Front shield

Item numbers
Front glove-box - Knee-guard panel PIAGGIO PIAGGIO-SCOOTER 125 CARNABY 2010 Carnaby 4T E3
1
2
2
3
3
4
5
5
6
6
6
6
6
6
6
6
7
8
9
10
11
12
13
1
COUNTER SHIELD

656646000C  

Contact
2
SCREW M4, 2X13

259349  

Unit Price Incl. Tax

3
EXPANSION PLUG

199190  

Unit Price Incl. Tax

3
CAP

230872  

Unit Price Incl. Tax

4
SCREW 4, 2X19

258249  

Unit Price Incl. Tax

5
SPRING PLATE

CM017410  

Unit Price Incl. Tax

6
LEG SHIELD BACK PLATE COVER

653251  

Contact
6
LEG SHIELD BACK PLATE COVER

65325100AL  

Unit Price Incl. Tax

6
LEG SHIELD BACK PLATE COVER

65325100DE  

Contact
6
LEG SHIELD BACK PLATE COVER

65325100ET  

Unit Price Incl. Tax

6
LEG SHIELD BACK PLATE COVER

65325100EU  

Contact
6
LEG SHIELD BACK PLATE COVER

65325100M4  

Contact
6
LEG SHIELD BACK PLATE COVER

65325100ND  

Contact
6
LEG SHIELD BACK PLATE COVER

65325100XN2  

Unit Price Incl. Tax

7
SCREW W/ FLANGE M5X16

AP8152298  

Unit Price Incl. Tax

8
SPRING PLATE M5

248419  

Unit Price Incl. Tax

9
BAG HOLDER HOOK

575819  

Unit Price Incl. Tax

10
SCREW M4, 2X13

259349  

Unit Price Incl. Tax

11
EXPANSION TANK PLUG

653253000C  

Unit Price Incl. Tax

12
SELF TAPPING SCREW

297498  

Unit Price Incl. Tax

13
COMPLETE LEG SHIELD BACK PLATE

654526  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Front glove-box - Knee-guard panel of your PIAGGIO Carnaby 4T E3 of CARNABY. Let us know if you have any questions.
