CRANKCASE COVER - CRANKCASE COOLING FOR PIAGGIO FLY 4T/3V IE E3 LEM 2012

Silencer

Item numbers
Crankcase cover - Crankcase cooling PIAGGIO PIAGGIO-SCOOTER 125 FLY 2012 Fly 4T/3V ie E3 LEM
1
2
2
3
4
5
6
6
6
6
7
8
9
10
11
12
13
13
14
15
16
17
1
TRANSMISSION COVER CPL.

B0176695  

Unit Price Incl. Tax

2
PIN D.9, 5 H=15

B015956  

Unit Price Incl. Tax

3
RADIAL BEARING 15X35X11
BALL BEARING

83057R  

4789853

Unit Price Incl. Tax

4
SNAP RING

006635  

Contact
5
COVER GASKET

B016453  

Unit Price Incl. Tax

6
SCREW M6X35

1A000348  

Unit Price Incl. Tax

6
SCREW M6X35

414838  

Unit Price Incl. Tax

7
HOSE CLAMP

668643  

Unit Price Incl. Tax

8
COOLING COVER

1A000068  

1A001166

Unit Price Incl. Tax

9
RETAINER BUFFER
DUMPE

B016983  

871458

Unit Price Incl. Tax

10
TRANSMISSION COVER

CM166002  

Unit Price Incl. Tax

11
HOSE

672258  

Unit Price Incl. Tax

12
HEX SOCKET SCREW M5X14

B016455  

Unit Price Incl. Tax

13
HOSE CLAMP

781328  

Unit Price Incl. Tax

14
HOSE CLAMP

844964  

Unit Price Incl. Tax

15
METRIC SCREW M6X22

CM179201  

Unit Price Incl. Tax

16
BELT COOLING CONDUIT

673825  

Unit Price Incl. Tax

17
SPRING PLATE M6

254485  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO Fly 4T/3V ie E3 LEM 2012
