CRANKCASE COVER - CRANKCASE COOLING FOR PIAGGIO FLY 4T E3 2012

Silencer

Item numbers
Crankcase cover - Crankcase cooling PIAGGIO PIAGGIO-SCOOTER 125 FLY 2012 Fly 4T E3
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
19
20
1
TRANSMISSION COVER CPL.
CRANKCASE COVER ASSY

871470  

8413805

Unit Price Incl. Tax

2
RADIAL BEARING 15X35X11
BALL BEARING

478985  

4789853

Unit Price Incl. Tax

3
SNAP RING

006635  

Contact
4
BUSH Ø8XØ12X8

431860  

Unit Price Incl. Tax

5
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price Incl. Tax

6
AIR DEFLECTOR

873682  

Unit Price Incl. Tax

7
SELF-TAPPING SCREW

430264  

Unit Price Incl. Tax

8
SCREW W/ FLANGE M6X30
FLANGED HEXAGONAL HEAD SCREW (M6X30)

289731  

B016792

Unit Price Incl. Tax

9
HOSE CLAMP

844964  

Unit Price Incl. Tax

10
RETAINER BUFFER

871458  

Unit Price Incl. Tax

11
TRANSMISSION COVER
TRANSMISSION COVER CAP

CM155101  

CM155110

Unit Price Incl. Tax

12
COOLING COVER

876166  

Unit Price Incl. Tax

13
TBCIC SCREW

270793  

Unit Price Incl. Tax

14
HOSE

672258  

Unit Price Incl. Tax

15
HOSE CLAMP

709519  

Unit Price Incl. Tax

16
BELT COOLING CONDUIT

673825  

Unit Price Incl. Tax

17
CLAMP

482291  

1C006656

Unit Price Incl. Tax

18
SCREW W/ FLANGE M6X30
FLANGED HEXAGONAL HEAD SCREW (M6X30)

289731  

B016792

Unit Price Incl. Tax

19
SELF-TAP SCREW

478533  

Unit Price Incl. Tax

19
SELF-TAP SCREW

781193  

Contact
20
SPRING PLATE M6

254485  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO Fly 4T E3 2012

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Fly 4T E3 2012

All the genuine spare parts for the PIAGGIO 2012

125 FLY 2012 Fly 4T E3

Fly 4T E3

Piaggio - Scooter FLY

Displacement: 125 cc
Year: 2012
