Rear suspension - Shock absorber / s

REAR WHEEL FOR PIAGGIO FLY 4T/3V IE E3 LEM 2013

Swinging arm

Item numbers
Rear wheel PIAGGIO PIAGGIO-SCOOTER 125 FLY 2013 Fly 4T/3V ie E3 LEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
14
1
SCREW

597564  

Unit Price Incl. Tax

2
BRAKE DISC

56484R  

Unit Price Incl. Tax

3
REAR WHEEL HUB

598715  

Unit Price Incl. Tax

4
SELF LOCKING NUT

597565  

Unit Price Incl. Tax

5
REAR WHEEL

668013  

Unit Price Incl. Tax

6
TUBELESS TYRE VALVE

270991  

Contact
7
FLAT WASHER 15X8, 4X1, 5

003058  

Contact
8
SPRING WASHER

709047  

Unit Price Incl. Tax

9
HEX SOCKET SCREW M8X40

149104  

Unit Price Incl. Tax

10
REAR WHEEL SPACER

668481  

Unit Price Incl. Tax

11
NUT M16X13

563728  

Unit Price Incl. Tax

12
NUT SECURING

194423  

1C004746

Unit Price Incl. Tax

13
SPLIT PIN

012789  

Contact
14
TYRE (SAVA) 120/70-12"

598277  

Unit Price Incl. Tax

14
TYRE (CHENG SHIN) 120/70 R12

664014  

Unit Price Incl. Tax

14
TYRE (DURO) 120/70 R12

666867  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO Fly 4T/3V ie E3 LEM 2013

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system
