ELECTRICAL SYSTEMS FOR PIAGGIO HEXAGON LX4 1998

Battery

Item numbers
Electrical systems PIAGGIO PIAGGIO-SCOOTER 125 HEXAGON 1998 HEXAGON LX4
1
2
3
15
16
17
18
19
20
21
22
23
24
1
SCREW M4, 2X13

259349  

Unit Price Incl. Tax

2
PLATE
SPRING PLATE

008080  

CM017408

Unit Price Incl. Tax

3
REM. CONTROL SWITCH 12V-30A
CONTACTOR 12V 30A GROUP

294076  

58246R

Unit Price Incl. Tax

10
FUSE 25A

291570  

Unit Price Incl. Tax

15
STARTER RELAY 12V-80A
REMOTE CONTROL SWITCH 12V-80A

580062  

58115R

Unit Price Incl. Tax

16
SCREW M6X16

272836  

Unit Price Incl. Tax

17
FLAT WASHER 6, 4X12X1

003056  

Unit Price Incl. Tax

18
NUT

709116  

Unit Price Incl. Tax

19
WASHER

179575  

Unit Price Incl. Tax

20
SPRING WASHER 6, 4X11, 8X1

016406  

Contact
21
ENGINE-FRAME GROUND WIRING
ENGINE EARTH BRIDE

580555  

Contact
22
SCREW M6X16

031088  

Contact
23
FLAT WASHER 6, 4X12X1

003056  

Unit Price Incl. Tax

24
CABLE

292926  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Electrical systems of your PIAGGIO HEXAGON LX4 of HEXAGON. Let us know if you have any questions.

Genuine parts for PIAGGIO HEXAGON LX4 1998
