OIL PUMP FOR PIAGGIO HEXAGON LX4 1999

Oil radiator

Item numbers
Oil pump PIAGGIO PIAGGIO-SCOOTER 125 HEXAGON 1999 HEXAGON LX4
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30
31
32
1
SPACER

478247  

4782476

Unit Price Incl. Tax

2
ROD

410226  

Contact
3
SLIDING BLOCK

436260  

Contact
4
HEX SCREW M6X18

031089  

Contact
5
OIL PUMP

436643  

Contact
6
WASHER Ø5, 3XØ10X0, 5

006975  

Contact
7
SCREW
SCREW WITH CYLINDRICAL HEAD (M5X30)

030251  

828493

Unit Price Incl. Tax

8
BELLEVILLE SPRING Ø6, 4XØ20X2

436695  

Unit Price Incl. Tax

9
SCREW W/ FLANGE M6X14
FLANGED HEXAGONAL HEAD SCREW M6X14

436788  

B016426

Unit Price Incl. Tax

10
PROTECTION

436810  

Contact
11
VIS TCIC M5X10
CROSS SLOTTED SCREW WITH CYLINDER HEAD

018575  

1A003111

Unit Price Incl. Tax

12
MOTOR OIL CUP
OIL PAN

485692  

844871

Unit Price Incl. Tax

13
VIS BRIDE M6X25
FLANGED HEXAGONAL SCREW M6X25

414837  

B016774

Unit Price Incl. Tax

14
OIL PUMP GEAR

287913  

Unit Price Incl. Tax

15
OIL PUMP CHAIN

434447  

Unit Price Incl. Tax

16
OIL PUMP CONTROL PINION
PUMP OIL PINION ET4 50/125 U

478149  

833495

Unit Price Incl. Tax

17
CARTER-OIL PUMP GASKET

436751  

Unit Price Incl. Tax

18
CHAIN

436246  

Unit Price Incl. Tax

19
PINION

434442  

Unit Price Incl. Tax

20
WASHER

430535  

Unit Price Incl. Tax

21
GASKET RING
RING

434478  

844888

Unit Price Incl. Tax

22
GASKET RING
RING

287963  

2879633

Unit Price Incl. Tax

23
OIL PUMP CHAIN DRIFT

434345  

Unit Price Incl. Tax

24
TIMING SYSTEM COVER CPL.

478324  

Unit Price Incl. Tax

25
TCCIC M5X16
CROSS SLOTTED SCREW WITH CYLINDER HEAD

015715  

1A003109

Unit Price Incl. Tax

26
OIL LEVEL ROD CPL.
OIL DIPSTICK

479996  

844721

Unit Price Incl. Tax

27
GASKET

479985  

Unit Price Incl. Tax

28
JOINT
GASKET "OR"

479986  

1A009397

Unit Price Incl. Tax

30
WASHER 5.3X10X10

006965  

Contact
31
OIL UNLOAD PLUG

436692  

Unit Price Incl. Tax

32
O-RING 20, 35X1, 78

288474  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Oil pump of your PIAGGIO HEXAGON LX4 of HEXAGON. Let us know if you have any questions.
