THROTTLE BODY - INJECTOR - UNION PIPE FOR PIAGGIO LIBERTY 4T 3V IE E3 2013

Crankshaft

Item numbers
Throttle body - Injector - Union pipe PIAGGIO PIAGGIO-SCOOTER 125 LIBERTY 2013 Liberty 4T 3V ie E3
1B
1A
2
2
3
4
5
6
6
7B
7A
8
9
10
11
12
13
1A
THROTTLE BODY WITH E.C.U.

CM088109  

Unit Price Incl. Tax

1B
THROTTLE BODY CPL.

1D000063R  

Unit Price Incl. Tax

2
UNION PIPE

1A000791  

Contact
3
GASKET
GASKET

B015678  

1A003750

Unit Price Incl. Tax

4
SCREW M6X25
BOLT

B016007  

Contact
5
INJECTOR COMPLETE WITH CONNECTION

8799715  

Unit Price Incl. Tax

6
SCREW W/ FLANGE M5X20

872269  

Unit Price Incl. Tax

7A
HOSE
INTAKE FITTING MANIFOLD

B016668  

1A002367

Unit Price Incl. Tax

7B
HOSE
INTAKE FITTING MANIFOLD

1A000273  

1A002367

Unit Price Incl. Tax

8
HOSE CLAMP
CLAMP Ø40-60

B016009  

614188

Unit Price Incl. Tax

9
HOSE CLAMP
HOSE CLAMP

B016006  

709532

Unit Price Incl. Tax

10
METALLIC CLAMP

642044  

Unit Price Incl. Tax

11
SCREW M5X15

873653  

Unit Price Incl. Tax

12
WASHER

012528  

Contact
13
TUBE SUPPORT BRACKET

1A000390  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for PIAGGIO Liberty 4T 3V ie E3 2013
