CRANKCASE FOR PIAGGIO HEXAGON LX BEFORE 200

Crankcase cover, clutch side

Item numbers
Crankcase PIAGGIO PIAGGIO-SCOOTER 180 HEXAGON Before 200 Hexagon LX
1
2
2
3
4
5
5
6
6
7
8
9
10
11
12
13
14
15
1
CRANK-CASE

826249  

Contact
2
STUD BOLT

433599  

Contact
3
NUT

020006  

Contact
4
RING

287223  

Unit Price Incl. Tax

5
RING

113533  

Unit Price Incl. Tax

6
NUT M8

020008  

Contact
7
SHOCK ABSORBER CONNECTION SILENT BLOCK

267823  

Unit Price Incl. Tax

8
SPACER

266625  

Unit Price Incl. Tax

9
SCREW W/ FLANGE M6X50
FLANGED HEXAGONAL SCREW M6X50

620068  

B016775

Unit Price Incl. Tax

10
PAD

270371  

Unit Price Incl. Tax

11
GASKET RING

4352035  

Unit Price Incl. Tax

12
BUSH Ø8XØ12X8
BENDIX BUSH

286143  

431860

Unit Price Incl. Tax

13
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price Incl. Tax

14
PAD

273884  

Contact
15
ROLLER CAGE

430228  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Crankcase of your PIAGGIO Hexagon LX of HEXAGON. Let us know if you have any questions.

Genuine parts for PIAGGIO Hexagon LX Before 200
