SUPPLY SYSTEM FOR PIAGGIO CARNABY 4T E3 2007

Wheel huosing - Mudguard

Item numbers
Supply system PIAGGIO PIAGGIO-SCOOTER 200 CARNABY 2007 Carnaby 4T E3
1
2
3
3
4
5
6
6
7
8
9
10
11
12
12
13
13
14
15
16
17
17
18
19
20
1
FUEL PUMP

639861  

Contact
2
ELECTRICAL PUMP SUPPORT

654047  

Unit Price Incl. Tax

3
VALVE
SAFETY VALVE

576469  

654935

Unit Price Incl. Tax

4
FUEL PIPE
R MIXER FEEDING PIPE

CM004126  

1R000160

Unit Price Incl. Tax

5
FUEL PIPE
R MIXER FEEDING PIPE

CM004126  

1R000160

Unit Price Incl. Tax

6
HOSE CLAMP

CM001901  

Unit Price Incl. Tax

7
FUEL FILTER

270423  

Unit Price Incl. Tax

8
FUEL FILTER SUPPORT

654108  

Unit Price Incl. Tax

9
VIS TCIC M5X10
CROSS SLOTTED SCREW WITH CYLINDER HEAD

018575  

1A003111

Unit Price Incl. Tax

10
WASHER 5.3X10X10

006965  

Contact
11
WASHER

078193  

Contact
12
FUEL PIPE
R MIXER FEEDING PIPE

CM004125  

1R000160

Unit Price Incl. Tax

13
HOSE CLAMP

CM001901  

Unit Price Incl. Tax

14
HOSE CLAMP

600452  

Unit Price Incl. Tax

15
SCREW M6X16

272836  

Unit Price Incl. Tax

16
SPRING PLATE M6

254485  

Unit Price Incl. Tax

17
HOSE CLAMP

CM001901  

Unit Price Incl. Tax

18
LOCK-STRAP L=180MM

145298  

Unit Price Incl. Tax

19
HOSE CLAMP

CM002905  

Unit Price Incl. Tax

20
FLEXIBLE SUPPORT

272842  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Supply system of your PIAGGIO Carnaby 4T E3 of CARNABY. Let us know if you have any questions.

Genuine parts for PIAGGIO Carnaby 4T E3 2007

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Carnaby 4T E3 2007

Choose the exact model of your PIAGGIO CARNABY 200 to access the different categories of genuine spare parts

200 CARNABY 2007 Carnaby 4T E3

Carnaby 4T E3

Piaggio - Scooter CARNABY

Displacement: 200 cc
Year: 2007
