FUEL TANK FOR PIAGGIO CARNABY 4T IE E3 2008

Helmet huosing - Undersaddle

Item numbers
Fuel tank PIAGGIO PIAGGIO-SCOOTER 250 CARNABY 2008 Carnaby 4T ie E3
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
20
1
FUEL TANK

654923  

Contact
1
SELF-TAPPING SCREW

CM179101  

Unit Price Incl. Tax

2
SELF TAPPING SCREW L=20 MM

267958  

Unit Price Incl. Tax

3
FLAT WASHER Ø5, 3XØ14X1
WASHER X SILENCER PROTECTION(5, 2X14X0, 6)

060201  

Contact
4
HEX SCREW M6X20

018639  

Contact
5
WASHER 6, 2X18X2

013950  

Contact
6
SPRING PLATE M6

254485  

Unit Price Incl. Tax

7
PLUG

259832  

Unit Price Incl. Tax

8
TANK COVER GASKET

258160  

Unit Price Incl. Tax

9
FUEL COLLECTOR RUBBER

AP8144187  

Unit Price Incl. Tax

10
2-WAY UNION

AP8101944  

Unit Price Incl. Tax

11
LEVEL GAUGE

CM025710  

Unit Price Incl. Tax

12
TANK BREATHER PIPE Ø5X10 L.1060

CM001432  

Unit Price Incl. Tax

13
HOSE CLAMP

CM002905  

Unit Price Incl. Tax

14
GASKET
GASKET

576542  

656003

Unit Price Incl. Tax

15
FUEL PUMP

858506  

Unit Price Incl. Tax

16
RING NUT

576546  

Unit Price Incl. Tax

17
HOSE CLAMP

573918  

Unit Price Incl. Tax

18
PIPES/CABLES RETAINER SPRING

CM006913  

Unit Price Incl. Tax

19
HOSE CLAMP

269273  

Unit Price Incl. Tax

19
HOSE CLAMP
PIPE RETAINING CLIP WITH RUBBER SLEEVE

623743  

675510

Unit Price Incl. Tax

20
FUEL PIPE

656065  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Fuel tank of your PIAGGIO Carnaby 4T ie E3 of CARNABY. Let us know if you have any questions.
