BRAKES PIPES - CALIPERS (ABS) FOR PIAGGIO X10 4T 4V I.E. E3 2013

Transmissions

Item numbers

RH BRAKE CALIPER

CM068316

Contact

BRAKE PADS COUPLE

668017

£71,78

Unit Price Incl. Tax

BRAKE SUPP. PLATE PIN

666139

£12,19

Unit Price Incl. Tax

LH BRAKE CALIPER

CM068319

£331,64

Unit Price Incl. Tax

(HENG TONG) BRAKE PADS COUPLE

651253

£35,33

Unit Price Incl. Tax

BRAKE SUPP. PLATE PIN

666139

£12,19

Unit Price Incl. Tax

TORX CONVEX BIG END SCREW

651297

£1,03

Unit Price Incl. Tax

SPRING WASHER

709047

£0,66

Unit Price Incl. Tax

ABS UNIT
ABS UNIT

667981

1C001972

£1 516,00

Unit Price Incl. Tax

SUPPORT CLAMP

668264

£20,61

Unit Price Incl. Tax

ABS SUPPORT BRACKET WITH I.P.

668058

£56,76

Unit Price Incl. Tax

HEX SCREW M6X20

018639

Contact

SPACER

174969

£1,43

Unit Price Incl. Tax

WASHER

179575

£1,28

Unit Price Incl. Tax

PAD

939278

£4,27

Unit Price Incl. Tax

SCREW W/ FLANGE M6X14

874554

£2,20

Unit Price Incl. Tax

SCREW W/ FLANGE

598839

£1,21

Unit Price Incl. Tax

CONICAL WASHER

834951

£1,12

Unit Price Incl. Tax

ABS UNIT RIGHT BRAKE PUMP PIPE

668215

£68,96

Unit Price Incl. Tax

ABS UNIT BRAKE PIPE - FRONT BRAKE PIN

668216

£69,99

Unit Price Incl. Tax

ABS UNIT - LEFT BRAKE PUMP PIPE

668214

£68,96

Unit Price Incl. Tax

ABS BRAKE PIPE - VALVE

668217

£68,04

Unit Price Incl. Tax

PRESSURE ADJUSTING VALVE

CM086101

£112,25

Unit Price Incl. Tax

HEX SOCKET SCREW M6X16

709099

£0,13

Unit Price Incl. Tax

SPRING WASHER 12X6, 4X0, 5

006976

OIL PIPE SCREW M10X18

265451

£2,40

Unit Price Incl. Tax

GASKET

127927

£0,99

Unit Price Incl. Tax

BRAKE PIPE (VALVE-CALIPER)

668231

£61,03

Unit Price Incl. Tax

REAR BRAKE PIPE

668692

£204,99

Unit Price Incl. Tax

ÉTRIER DE FREIN D
RIGHT CALIPER

CM068318

CM294406

£239,21

Unit Price Incl. Tax

(HENG TONG) BRAKE PADS COUPLE

665842

£35,00

Unit Price Incl. Tax

BRAKE SUPP. PLATE PIN

666139

£12,19

Unit Price Incl. Tax

HEX SCREW

668136

£2,91

Unit Price Incl. Tax

WASHER
PLANE SPRING WASHER

709646

Contact

PARKING BRAKE CALLIPER

CM084602

£363,62

Unit Price Incl. Tax

BRAKE PADS COUPLE

668541

£39,91

Unit Price Incl. Tax

HEX SOCKET SCREW

826298

£1,15

Unit Price Incl. Tax

SPRING WASHER

709047

£0,66

Unit Price Incl. Tax

HOSE CLAMP

598795

£2,04

Unit Price Incl. Tax

SCREW W/ FLANGE M6X14

874554

£2,20

Unit Price Incl. Tax

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

£1,21

Unit Price Incl. Tax

HOSE CLAMP

668866

£9,80

Unit Price Incl. Tax

HOSE CLAMP

668303

£15,75

Unit Price Incl. Tax

HOSE CLAMP

667156

£4,62

Unit Price Incl. Tax

HOSE CLAMP

666047

£3,68

Unit Price Incl. Tax

HOSE CLAMP
PIPE RETAINING CLIP WITH RUBBER SLEEVE

623743

675510

£3,79

Unit Price Incl. Tax

LOCK-STRAP L=180MM

145298

£1,09

Unit Price Incl. Tax

SPRING

CM013201

£0,73

Unit Price Incl. Tax

NON RETURN SPRING

CM006902

£1,48

Unit Price Incl. Tax

SPRING

179013

£4,95

Unit Price Incl. Tax

HEX SCREW M8X22

031119

£1,49

Unit Price Incl. Tax

COMPLETE COVER

651318

Contact

BUSHING

650884

£6,66

Unit Price Incl. Tax

HEX SOCKET SCREW M6X12

274369

£0,61

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of PIAGGIO, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
