CRANKCASE FOR VESPA GTS 4T E4 ABS 2016

Crankcase cover - Crankcase cooling

Item numbers

COMPLETE CRANKCASE 1ST CLASS

CM2588010A

CM2856010A

£961,71

Unit Price Incl. Tax

COMPLETE CRANKCASE 2ND CLASS

CM2588010B

CM30740102

£961,71

Unit Price Incl. Tax

STUD BOLT

1A001406

£4,07

Unit Price Incl. Tax

PLUG M12X1, 5X11

B015433

£7,50

Unit Price Incl. Tax

PIN D.9, 5 H=15

B015956

£0,71

Unit Price Incl. Tax

RADIAL BEARING 15X42X13

83026R

£5,26

Unit Price Incl. Tax

LOCATING DOWEL

B015957

£0,95

Unit Price Incl. Tax

CIRCLIP 25X26, 9X1, 2

B015959

£1,21

Unit Price Incl. Tax

RADIAL BEARING 20X50X14

83027R

£10,66

Unit Price Incl. Tax

GASKET RING 20.35.7

1A005746

£8,94

Unit Price Incl. Tax

GASKET RING 24.35.7

1A005745

£8,94

Unit Price Incl. Tax

STUD BOLT

1A001860

£7,09

Unit Price Incl. Tax

LOCATING DOWEL

484993

£1,12

Unit Price Incl. Tax

CALIBRATED NOZZLE

1A001364

£4,15

Unit Price Incl. Tax

SILENT-BLOCK

486081

£9,31

Unit Price Incl. Tax

PISTON COOLING JET

1A002024

£10,74

Unit Price Incl. Tax

SCREW

1A005607

£2,56

Unit Price Incl. Tax

O-RING

273754

£0,70

Unit Price Incl. Tax

OIL PRESSURE ADJUSTING VALVE

B015432

Contact

VALVE SPRING

B015431

£1,17

Unit Price Incl. Tax

OIL BULHEAD

B014134

£9,22

Unit Price Incl. Tax

UPPER OIL BULKHEAD

B014135

£6,80

Unit Price Incl. Tax

SCREW W/ FLANGE M5X16

830061

£2,37

Unit Price Incl. Tax

HALF CRANKCASE GASKET

1A001115

£9,36

Unit Price Incl. Tax

FILTER DOOR INSERT

B015430

£6,03

Unit Price Incl. Tax

GASKET

431065

£0,86

Unit Price Incl. Tax

SCREW W/ FLANGE M6X60

B016425

£1,55

Unit Price Incl. Tax

HEX SOCKET SCREW M8X12

269755

£1,30

Unit Price Incl. Tax

WASHER 8.2X12X1

485703

£0,91

Unit Price Incl. Tax

AIR DUCT

1A006689

£10,62

Unit Price Incl. Tax

TORX SCREW M5X20

B016808

£1,21

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Crankcase of your VESPA GTS 4T E4 ABS of GTS. Let us know if you have any questions.
