Finish line

Parts catalogue

Parts diagram

Stater - Electric starter

CRANKCASE FOR VESPA PX 2016

Crankcase cover - Crankcase cooling

Item numbers
Crankcase VESPA VESPA-SCOOTER 150 PX 2016 PX
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
28
28
29
30
31
32
33
1
CRANKCASE ASSEMBLY

8410315  

Unit Price Incl. Tax

2
STUD, MIDDLE ROOT

011288  

Contact
3
STUD BOLT

150656  

Unit Price Incl. Tax

4
STUD BOLT

003972  

Contact
5
SCREW

156400  

Unit Price Incl. Tax

6
RING

059589  

Contact
7
RING

047945  

Contact
8
PIPE

047944  

Contact
9
RING

059590  

Contact
10
RING

059588  

Contact
11
RING

048988  

Contact
12
SPACER

223604  

Unit Price Incl. Tax

13
LOCATING DOWEL

484993  

Unit Price Incl. Tax

14
RIB

146129  

Unit Price Incl. Tax

15
SHELL

174514  

Unit Price Incl. Tax

16
NUT

020107  

Contact
17
PAD

178338  

Unit Price Incl. Tax

18
FLAT WASHER

003057  

Contact
19
WASHER
WASHER

006977  

Contact
20
NUT

020107  

Contact
21
NUT

238969  

Unit Price Incl. Tax

22
WASHER
WASHER

006977  

Contact
23
GASKET

078163  

Contact
24
DUST COVER

0784825  

Contact
25
BOLT

008419  

Contact
25
BOLT

014565  

Contact
26
HALF CRANKCASE GASKET

B013737  

Unit Price Incl. Tax

27
SCREW

121668  

Unit Price Incl. Tax

28
GASKET

139433  

Unit Price Incl. Tax

29
SPRING

078521  

Contact
30
BOLT

012485  

Contact
31
NUT

020207  

Contact
32
SCREW

023823  

Contact
33
NUT

020105  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Crankcase of your VESPA PX of PX. Let us know if you have any questions.

Genuine parts for VESPA PX 2016

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

VESPA PX 2016

Choose the exact model of your VESPA PX 150 to access the different categories of genuine spare parts

150 PX 2016 PX

PX

Vespa - Scooter PX

Displacement: 150 cc
Year: 2016
