Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Crankcase

CRANKCASE COVER - CRANKCASE COOLING FOR GILERA NEXUS IE E3 2009

Crankshaft

Item numbers
Crankcase cover - Crankcase cooling GILERA GILERA-SCOOTER 125 NEXUS 2009 Nexus ie E3
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
1
TRANSMISSION COVER WITH U.P.
TRANSMISSION COVER WITH I.P.

8772935  

8768835

Unit Price Incl. Tax

2
SNAP RING

006635  

Contact
3
RADIAL BEARING 15X35X11
BALL BEARING

478985  

4789853

Unit Price Incl. Tax

4
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price Incl. Tax

5
COOLING COVER

876075  

1A014715

Unit Price Incl. Tax

6
SCREW M6X25

018553  

Contact
7
FILTERING ELEMENT

875701  

Unit Price Incl. Tax

8
SCREW W/ FLANGE M6X30
FLANGED HEXAGONAL HEAD SCREW (M6X30)

289731  

B016792

Unit Price Incl. Tax

9
HOSE CLAMP

844964  

Unit Price Incl. Tax

10
SOUNDPROOFING PROTECTION

876428  

Unit Price Incl. Tax

11
SPRING PLATE

181351  

Unit Price Incl. Tax

12
SCREW W/ FLANGE M6X50
FLANGED HEXAGONAL SCREW M6X50

430207  

B016775

Unit Price Incl. Tax

13
SPACER

431577  

Unit Price Incl. Tax

14
COVER WITH LOGOTYPE "GILERA"

CM159901  

Unit Price Incl. Tax

15
PROTECTION

652802  

Unit Price Incl. Tax

16
KNURLED BUSHING

830056  

Unit Price Incl. Tax

17
SCREW M6X35

414838  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from GILERA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of GILERA, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for GILERA Nexus ie E3 2009

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

GILERA Nexus ie E3 2009

All the genuine spare parts for the GILERA 2009

125 NEXUS 2009 Nexus ie E3

Nexus ie E3

Gilera - Scooter NEXUS

Displacement: 125 cc
Year: 2009
New and original manufacturer parts
Official GILERA price
