COOLING SYSTEM FOR GILERA NEXUS IE E3 2009

Side cover - Spoiler

Item numbers

TANK

975031

£98,08

Unit Price Incl. Tax

EXPANSION TANK PLUG

623673

£17,12

Unit Price Incl. Tax

FUEL TANK GASKET

620737

£2,07

Unit Price Incl. Tax

TANK-COOLER FEED PIPE

CM007007

£17,78

Unit Price Incl. Tax

HOSE CLAMP

CM001914

£1,49

Unit Price Incl. Tax

COOLER-TANK RETURN PIPE

975696

£22,04

Unit Price Incl. Tax

HOSE CLAMP

CM001921

£3,50

Unit Price Incl. Tax

BRACKET

975592

£14,35

Unit Price Incl. Tax

TBCIC SCREW

270793

£0,49

Unit Price Incl. Tax

LOWER RUBBER

258904

£1,47

Unit Price Incl. Tax

ELECTRIC FAN ASSY.
ELECTRIC FAN

58170R

58211R

£202,70

Unit Price Incl. Tax

SCREW M6X16

CM179301

£1,21

Unit Price Incl. Tax

SPRING PLATE M6

254485

£1,57

Unit Price Incl. Tax

WATER COOLER

57311R

£605,26

Unit Price Incl. Tax

METRIC SCREW M6X20

259830

Contact

WASHER D6, 2X20X1

013092

Contact

SPACER

273288

£1,79

Unit Price Incl. Tax

UPPER RUBBER

351782

£1,93

Unit Price Incl. Tax

LOWER RUBBER

258904

£1,47

Unit Price Incl. Tax

COVER

621365

£2,13

Unit Price Incl. Tax

COPPER GASKET

168077

£4,64

Unit Price Incl. Tax

PUMP RADIATOR JOINT PIPE

655644

£123,35

Unit Price Incl. Tax

CYLINDER-HEAD RADIATOR JOINT PIPE

654154

£65,27

Unit Price Incl. Tax

HOSE CLAMP

CM001915

£1,91

Unit Price Incl. Tax

LOCK-STRAP L=277

257134

£0,45

Unit Price Incl. Tax

HOSE CLAMP

CM001922

£1,91

Unit Price Incl. Tax

PIPES/CABLES RETAINER SPRING

CM006903

£3,42

Unit Price Incl. Tax

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

£1,21

Unit Price Incl. Tax

STIRRUP WITH I.P.

656004

£19,34

Unit Price Incl. Tax

CONVEYOR

654220

£18,02

Unit Price Incl. Tax

WASHER 4, 5X12X1

016670

Contact

RIVET

252099

£1,17

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from GILERA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of GILERA, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
