Oil pump

OIL RADIATOR FOR PIAGGIO HEXAGON LX4 2000

Rocker arm support

Item numbers
Oil radiator PIAGGIO PIAGGIO-SCOOTER 125 HEXAGON 2000 HEXAGON LX4
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
1
GUARD

482081  

Contact
2
RONDELLE 8.2X12X1
WASHER

000397  

485703

Unit Price Incl. Tax

3
OIL PLUG

138345  

Unit Price Incl. Tax

4
SELF TAPPING SCREW

297498  

Unit Price Incl. Tax

5
SELF-TAPPING SCREW M5X12

015585  

Contact
6
WASHER Ø5, 3XØ10X0, 5

006975  

Contact
7
FAN

436635  

Contact
8
HEX SOCKET SCREW M6X16

709099  

Unit Price Incl. Tax

9
MISSING DESCRIPTION

486195  

Contact
10
SPRING WASHER 6, 4X11X0, 5

006966  

Contact
11
OIL COOLER

435590  

Contact
12
WASHER
WASHER

436961  

Contact
13
PIPE

478416  

Unit Price Incl. Tax

14
SCREW

436948  

Unit Price Incl. Tax

15
PIPE

478415  

Contact
16
GUARD

482080  

Contact
17
COMPLETE OIL LEVEL DIPSTICK
OIL DIPSTICK COMPLETE

483850  

832130

Unit Price Incl. Tax

18
GASKET

483851  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Oil radiator of your PIAGGIO HEXAGON LX4 of HEXAGON. Let us know if you have any questions.
