STARTER ASSEMBLY FOR PIAGGIO HEXAGON LX4 2000

Carburettor

Item numbers

PAD

286207

£1,64

Unit Price Incl. Tax

PAD

478284

Contact

START.SHAFT

478723

Contact

STARTER LEVER RETURN SPRING

289495

£8,30

Unit Price Incl. Tax

SELF-TAPPING SCREW

430264

£0,61

Unit Price Incl. Tax

HOT AIR DEFLECTOR

479263

Contact

VIS BRIDE M6X25
FLANGED HEXAGONAL SCREW M6X25

414837

B016774

£1,21

Unit Price Incl. Tax

START. LEVER
KICKSTART LEVER

436901

827632

£55,40

Unit Price Incl. Tax

GASKET

435251

£7,67

Unit Price Incl. Tax

COVER

480077

Contact

SCREW

435295

£0,79

Unit Price Incl. Tax

TRANSMISSION COVER

484815

Contact

GASKET

479888

Contact

SCREW M6X35

414838

£1,21

Unit Price Incl. Tax

PAD

259625

£3,80

Unit Price Incl. Tax

WASHER 16, 3X23, 8

433987

£0,58

Unit Price Incl. Tax

CIRCLIP

006416

Contact

LOCK-STRAP L=277
RETAINING STRAP

109960

257134

£0,45

Unit Price Incl. Tax

BELLOWS

560503

Contact

HOSE CLAMP

298561

£4,06

Unit Price Incl. Tax

CONDOTTO ASPIR

574827

Contact

SCREW M4, 2X13

259349

£0,76

Unit Price Incl. Tax

SPRING PLATE
SPRING PLATE

184142

CM017410

£0,67

Unit Price Incl. Tax

PLATE

286206

Contact

GUARD

286217

£28,15

Unit Price Incl. Tax

STARTER LEVER
COMPLETE KICKSTART LEVER FOR MOTOR

286218

286214

£35,42

Unit Price Incl. Tax

RING

288041

£2,37

Unit Price Incl. Tax

WASHER 10, 1X2, 5

286219

£20,96

Unit Price Incl. Tax

SPRING PLATE
SPRING PLATE

184142

CM017410

£0,67

Unit Price Incl. Tax

WASHER

013963

Contact

SCREW M4, 2X13

259349

£0,76

Unit Price Incl. Tax

BELLOWS

574991

Contact

SCREW M6X35

414838

£1,21

Unit Price Incl. Tax

SPRING

273512

Contact

HOSE CLAMP

271477

£1,17

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Starter assembly of your PIAGGIO HEXAGON LX4 of HEXAGON. Let us know if you have any questions.
