Guidon - Maître cylindre

BRAS OSCILLANT FOR PIAGGIO CARNABY 4T IE CRUISER 2010

Fourche / tube direction - Ensemble butée dir.

Item numbers
Bras oscillant PIAGGIO PIAGGIO-SCOOTER 300 CARNABY 2010 Carnaby 4T ie Cruiser
1
2
3
3
4
4
4
5
6
6
7
8
9
10
10
10
11
11
12
13
14
15
16
17
1
COMPLETE SWINGING ARM

651256  

Contact
2
CONNECTING ROD PIVOT PIN

AP8161019  

Unit Price Incl. Tax

3
WASHER 12, 2X22X2

AP8152018  

Unit Price Incl. Tax

4
BUSH

598917  

Unit Price Incl. Tax

5
SPACER

649123  

Unit Price Incl. Tax

6
ROLLER CAGE

600161  

Unit Price Incl. Tax

7
LOW SELF-LOCKING NUT M12*

AP8150432  

Unit Price Incl. Tax

8
SPACER

649122  

Unit Price Incl. Tax

9
FRAME PIVOT PIN

AP8121191  

Unit Price Incl. Tax

10
WASHER 12, 2X22X2

AP8152018  

Unit Price Incl. Tax

11
LOW SELF-LOCKING NUT M12*

AP8150432  

Unit Price Incl. Tax

12
HEX SOCKET SCREW M12X90

AP8150554  

Unit Price Incl. Tax

13
SILENT-BLOCK

AP8161155  

Unit Price Incl. Tax

14
ENGINE PIVOT PIN

AP8121192  

Unit Price Incl. Tax

15
WASHER 10, 5X21X2*

AP8150020  

Unit Price Incl. Tax

16
SPACER

AP8121628  

Unit Price Incl. Tax

17
SELF-LOCKING NUT

AP8152301  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Bras oscillant of your PIAGGIO Carnaby 4T ie Cruiser of CARNABY. Let us know if you have any questions.
