Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Roue avant

SUSPENSION ARRIèRE - AMORTISSEUR / S FOR PIAGGIO CARNABY 4T IE CRUISER 2010

Composants de la fourche (Kayaba)

Item numbers
Suspension arrière - Amortisseur/s PIAGGIO PIAGGIO-SCOOTER 300 CARNABY 2010 Carnaby 4T ie Cruiser
1
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
1
REAR SHOCK ABSORBER CPL.

649423  

Unit Price Incl. Tax

2
SCREW W/ FLANGE M8X40

AP8152290  

Unit Price Incl. Tax

3
SELF-LOCKING NUT M8

AP8152300  

Unit Price Incl. Tax

4
SHOCK ABSORBER SUPPORT

AP8134974  

Unit Price Incl. Tax

5
HEX SOCKET SCREW M10X45

AP8150038  

Unit Price Incl. Tax

6
WASHER 10, 5X21X2*

AP8150020  

Unit Price Incl. Tax

7
SHOCK ABSORBER BUSH

AP8161031  

Unit Price Incl. Tax

8
SELF-LOCKING NUT

AP8152301  

Unit Price Incl. Tax

9
SCREW W/ FLANGE M8X50

AP8152292  

Unit Price Incl. Tax

10
SELF-LOCKING NUT M8

AP8152300  

Unit Price Incl. Tax

11
RIGHT SUSPENSION ARM

876615  

Unit Price Incl. Tax

12
BALL BEARING

82545R  

Unit Price Incl. Tax

13
CIRCLIP

006647  

Contact
14
HEX SOCKET SCREW

826298  

Unit Price Incl. Tax

15
FLAT WASHER 15X8, 4X1, 5
FLAT WASHER

013776  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from PIAGGIO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Suspension arrière - Amortisseur/s of your PIAGGIO Carnaby 4T ie Cruiser of CARNABY. Let us know if you have any questions.

Genuine parts for PIAGGIO Carnaby 4T ie Cruiser 2010

Engine Frame - Plastic parts - Coachwork Handlebars/Steering Suspensions - Wheels Braking system - Transmissions Electrical system

PIAGGIO Carnaby 4T ie Cruiser 2010

Choose the exact model of your PIAGGIO CARNABY 300 to access the different categories of genuine spare parts

300 CARNABY 2010 Carnaby 4T ie Cruiser

Carnaby 4T ie Cruiser

Piaggio - Scooter CARNABY

Displacement: 300 cc
Year: 2010
