Parts Catalog
Driven pulley
6
Parts Diagram
Parts Catalog
Fork/steering tube - Steering bearing unit
by
Windshield - Glass
Driven pulley
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
1
Driven pulley complete with clutch
874579
Not Available
2
Ring nut
831618
£13,09 Unit Price incl. VAT
3
Centrifugal clutch assy
842564
Not Available
4
O-ring
831920
£7,51 Unit Price incl. VAT
5
New cup type
831195
£7,85 Unit Price incl. VAT
6
Variator spring
875427
£35,24 Unit Price incl. VAT
6
Spring
831196
Not Available
7
Cup
833051
£15,72 Unit Price incl. VAT
8
O-ring
831921
£5,98 Unit Price incl. VAT
9
Pin
845367
£9,11 Unit Price incl. VAT
10
Driven mobile half-pulley
843750
Not Available
11
Gasket ring
831623
Not Available
12
Complete fixed driven half-pulley
874578
£471,59 Unit Price incl. VAT
13
Snap ring
831619
Not Available
14
Bearing
831615
£45,52 Unit Price incl. VAT
15
Gasket ring
844806
£7,85 Unit Price incl. VAT
16
Roller cage
874572
£57,85 Unit Price incl. VAT
17
Gasket ring
825023
£25,76 Unit Price incl. VAT
18
Aluminium clutch drum
842917
£156,72 Unit Price incl. VAT
19
Spacer
830380
£46,27 Unit Price incl. VAT
20
Flat washer
833052
£1,57 Unit Price incl. VAT
21
Nut M18x1,5
829232
£4,69 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
