1
Engine displacement
150
2
Model
PRIMAVERA
3
Year
2020
4
Trim
Primavera 150 Euro 5 ABS
5
Parts Catalog
Transmissions
6
Parts Diagram
Parts Catalog
MAIN WIRING HARNESS
by
Driven pulley
Transmissions
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
Rear brake lever complete transmission
1C002832
£40,01 Unit Price incl. VAT
2
Adjuster pin
179640
£7,87 Unit Price incl. VAT
3
Registro freno posteriore
270310
£5,26 Unit Price incl. VAT
4
Plate
1C001736
£1,38 Unit Price incl. VAT
5
Hex socket screw M6x20
667152
£1,27 Unit Price incl. VAT
6
Hose clamp
709519
£0,29 Unit Price incl. VAT
7
Lock-strap L=277
257134
£0,48 Unit Price incl. VAT
8
Lock-strap L=180mm
145298
£1,14 Unit Price incl. VAT
9
Hose clamp
298729
£1,24 Unit Price incl. VAT
10
Pipes/cables retainer spring
CM013202
£2,60 Unit Price incl. VAT
11
Collier
1B008162
£4,52 Unit Price incl. VAT
12
Self tapping screw 4,2x16
015911
Not Available
13
Plate
CM017408
£0,30 Unit Price incl. VAT
14
Hose clamp
298729
£1,24 Unit Price incl. VAT
15
Hose clamp
298729
£1,24 Unit Price incl. VAT

Find the detailed Transmissions GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
