1
Engine displacement
300
2
Model
GTV
3
Year
2023
4
Trim
Vespa GTV 300 HPE E5 ABS RST
5
Parts Catalog
Reduction unit
6
Parts Diagram
Parts Catalog
FLYWHEEL COVER - OIL FILTER
by
STICKERS - LABELS
Reduction unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
Couvercle de réducteur avec pièces internes
1A0198835
£284,78 Unit Price incl. VAT
2
Gasket ring 38x50x7
83082R
£6,54 Unit Price incl. VAT
3
Bearing 30.55.13
1A005376R
£13,13 Unit Price incl. VAT
4
Circlip
829206
£1,36 Unit Price incl. VAT
5
Radial ball bearing 15x42x13
83018R
£10,26 Unit Price incl. VAT
6
Arbre trnsmission
1A020476
£337,80 Unit Price incl. VAT
7
Driven pulley shaft Z=14
8738755
£224,71 Unit Price incl. VAT
8
Axe de roue arrière avec pièces internes
1A020472
£201,05 Unit Price incl. VAT
9
Gasket
847931
£7,80 Unit Price incl. VAT
10
Reduction unit breather pipe assembly
CM162202
£19,60 Unit Price incl. VAT
11
Screw w/ flange M8x40
B016806
£1,24 Unit Price incl. VAT
12
Screw w/ flange M8x45
B016805
£1,27 Unit Price incl. VAT
13
Hex socket screw M8x12
269755
£1,36 Unit Price incl. VAT
14
Washer 8.2x12x1
485703
£0,96 Unit Price incl. VAT

Find the detailed :label GILERA PIAGGIO VESPA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original GILERA PIAGGIO VESPA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
